Where do I find the control panel for intellitouch?

Where do I find the control panel for intellitouch?

Conveniently located in a weather-protected location in the home you will find the Indoor Control Panel. This is your primary means of controlling the IntelliTouch system. It consists of an easy-to-read LCD display, 10 status LED’s, 10 side buttons, and 5 lower buttons.

How does intellitouch control a pool and spa?

First is the Power Center which is installed at your pool equipment and contains all the electrical circuitry. Second is one of the “Personality Kits” you select based on whether you want to control a separate pool or spa, a pool/spa combination with shared equipment or a pool/spa combination with separate equipment.

Do you have to be licensed electrician to use intellitouch?

1. All work must be performed by a licensed electrician, and must conform to all national, state, and local codes. 2. Install to provide drainage of compartment for electrical components. 3. If this device is used to control underwater lighting fixtures, a ground-fault interrupter (GFCI) must be provided for these fixtures.

Conveniently located in a weather-protected location in the home you will find the Indoor Control Panel. This is your primary means of controlling the IntelliTouch system. It consists of an easy-to-read LCD display, 10 status LED’s, 10 side buttons, and 5 lower buttons.

What kind of pool control system does Pentair use?

IntelliTouch® automation offers superior control systems from small to the most ambitious pool and spa designs including water features and spectacular lighting effects. All available from Pool Supply Unlimited.

How many functions can an intellitouch pool control system handle?

There is an IntelliTouch system for every application pool, spa, pool and spa combinations and pools with separate spas. With the ability to control from five to forty functions, total backyard automation is achieveable. 1) The Enclosure Kit installed at your equipment pad that contains all the electrical circuitry.

Where is the terminal bar located on intellitouch?

A terminal bar stamped is located inside the supply terminal box. To reduce the risk of electric shock, this terminal must be connected to the grounding means provided in the electric supply service panel with a continuous copper wire equivalent in size to the circuit conductors supplying this equipment (no smaller than 12 AWG or 3.3mm).
